12" + 1" Coaxial Active Stage Monitor 400w + 100w
The StageMaxX 12 MA is a Processed Active Reinforcement Stage Monitor. Featuring a 400W + 100W RMS amp module delivering 130dB SPL. inside we have a Coaxial custom FBT 12” B&C speakers with 64mm (2.5”) voice coil with a B&C 25mm (1”) exit throat compression driver and 44mm (1.7”) voice coil, outside we have a sturdy gas-injected polypropylene molded enclosure to avoid undesired resonance. All proudly made in Italy.
Processed Active Reinforcement Monitor
400W + 100W RMS – 130dB SPL
The 4 presets are:
ORIGINAL: is the typical “MaxX” sound adapted to “STAGE” application
HI-CUT / DRUM FILL: provides less mid-high for a comfortable listening in near-field at high level
LO-CUT / DOUBLE: provides less low frequency for better intelligibility and for optimal coupling in stereo configuration
FOH: Front Of House use in suspended or pole-mount installations
MaxX More! The new stage monitor without compromise
FBT’s new StageMaxX 12Ma has been inspired by the need to have a product specifically designed and engineered for use as stage monitor, overcoming all these compromises for a full user satisfaction.
Key Features:
Low profile and aesthetic elegance
Compact size
Frequency response studied for stage monitor applications
High headroom before feedback
High sound quality
Great power and dynamics
Symmetric dispersion
Aligned LF and HF acoustic centers
Easy handling on stage
Lightweight
Heavy-duty polypropylene cabinet
Specifications:
Configuration 2 Way
Frequency response 60hz - 20 kHz
Low frequency woofer 12"
High frequency driver 1"
Maximum SPL cont/peak 124 / 130dB
Dispersion 90 x 90 (HxV)
Input impedance 22kohm
Crossover frequency 1.8kHz
Input connector XLR with link out
Net Dimension (WxHxD) 550 x 289 x 392mm
Net Weight 13.6 kg
Transport Dimension (WxHxD) 670 x 430 x 500mm
Transport Weight 16.4kg
AC Power requirements 450VA
Built-in amplifier LF/HF 400/100w RMS
Built-in amplifier peak LF/HF 800/200w
Power cord 5m PowerCon True1
