80x 15 W RGBWW strobe LEDs (10-section control)
84x 1 W RGB LEDs (28-section control)
Easy coupling system
IP65 rating
The Titan Vintage FX is an advanced strobe light fixture with a striking retro aesthetic, thanks to its chrome reflector that recalls the look of classic discharge strobes. Equipped with the latest technology, it boasts 80x 15-watt RGBWW strobe LEDs and 84x 1-watt RGB LEDs. The strobe LEDs can be controlled in 10 different sections, allowing the creation of colourful bursts and chases. The 84 RGB LEDs can be divided into 28 different sections, making them ideal for crafting colourful, dynamic backlight effects.
The IP65-rated housing makes the Titan Vintage FX suitable for all sorts of indoor and outdoor events. With DMX (+ RDM) and manual control options, 3-pin & 5-pin XLR and Power Pro True inputs and outputs, this strobe fixture can be easily integrated into any setup. Optional Titan Connection Blocks make it possible to quickly and easily combine multiple fixtures into unique horizontal and vertical setups.
Specifications:
Source
Light Source Type LED
Light Source Quantity 2
Light Source Power 15 W
LED Colour Type RGB, RGBW
Control and Programming
Control Mode DMX, RDM
Dynamic Effects
Strobe 0-25 Hz
Electrical Specifications and Connections
Power Supply 100-240 V AC 50/60 Hz
Power Consumption 1000 W
Power Connector In Power Pro True
Power Connector Out Power Pro True
DMX Connector XLR 3P In/Out, XLR 5P In/Out
DMX Connector In XLR 3P, XLR 5P
DMX Connector Out XLR 3P, XLR 5P
Mechanical Specifications
Height (mm) 200 mm (7.874″)
Width (mm) 407 mm (16.024″)
Depth (mm) 169 mm (6.654″)
Weight 8.2 kg (18.078 lb)
IP Rating IP65
Housing Aluminium die-cast
Colour Black
Product Properties
Cooling Forced Convection
Rigging
Mounting Options Clamp, Quick-Lock
Safety Attachment Yes
Thermal Specifications
Maximum Ambient Temperature 40 °C (104 °F)
Minimum Ambient Temperature -5 °C (23 °F)
Included Items
Included Cables Power Pro True Cable
