Solid and reliable 14x 5 W RGBW LED Spot
16° fixed beam angle
IP65 (dust and water resistant, fit for outdoor use)
Dimmer and strobe function
DMX and Master/Slave control
The Showtec Spectral M800 Q4 IP65 is a solid and reliable 14x 5 watt RGBW LED Spot suitable for outdoor venues. Each function and effect, including its 0 - 100 % dimmer, 0 - 20 Hz strobe function and colour mixing engine, is controllable via DMX and Master/Slave in either Manual and Auto run mode. The Spectral M800 Q4 IP65 projects a bright, soft field of coloured light with a 16° fixed beam angle. Its silent, fanless operation and strong 4.8 kg design makes it a very popular Spot, added at almost every lightshow and at any event or festival in Europe.
Specifications:
Source
Light Source Type LED
Light Source Quantity 14
Light Source Power 5 W
LED Colour Type RGBW
Refresh Rate (Max.) 25 kHz
Illuminance @ 2 m 8047 lx
Illuminance @ 3 m 3576 lx
Illuminance @ 5 m 1288 lx
Luminous Flux (Total) 2638 lm
CRI 70
Optical
Beam Angle (Circular) 16 °
Control and Programming
Control Mode Auto, Built-in Program, DMX, Manual, Master Slave
DMX Channels 4, 5, 6, 7, 9, 10, 13, 15
Protocols DMX, RDM
Display 7-segment
Dynamic Effects
Dimmer 0-100 %
Strobe 0-20 Hz
Electrical Specifications and Connections
Power Supply 100-240 V AC 50/60 Hz
Power Consumption 65 W
Power Connector In powerCON TRUE1
Power Connector Out powerCON TRUE1
DMX Connector Dedicated 3P IP65 In/Out
DMX Connector In Dedicated 3P IP65
DMX Connector Out Dedicated 3P IP65
Cable Length 1.5 m
Mechanical Specifications
Length (mm) 180 mm (7.087?)
Width (mm) 235 mm (9.252?)
Height (mm) 320 mm (12.598?)
Weight 5.2 kg (11.464 lb)
IP Rating IP65
Housing Aluminium die-cast
Colour Black
Product Properties
Cooling Convection
Thread M12
Rigging
Mounting Options Clamp, Surface
Safety Attachment Yes
Thermal Specifications
Maximum Ambient Temperature 40 °C (104 °F)
Minimum Operating Temperature -10 °C (14 °F)
Included Items
Included Cables powerCON TRUE1 cable
Included Rigging Bracket, Safety Cable
