Showtec Quick DMX D512S

Metal road proof casing
Power & Link indication LEDs at front panel
Unlimited nr. of different fixtures
Full 512 DMX channels
MIDI triggerable by "learning" mode

With the "D512S" interface it is possible to use Quick DMX software without any restriction for all 512 DMX channels. This interface can store one scene or chase for 512 DMX channels that will be played if connection with computer is lost.

Please note that Quick DMX D512S only works with Quick DMX software.

Specifications:

Software Specifications
Supported Operating Systems Mac, Windows

Control and Programming
Control Mode Manual, MIDI, PC Software, Stand Alone
DMX Channels 512
Universes 1

Electrical Specifications and Connections
Power Supply 5 V DC
Power Consumption 5 W
Power Connector In USB
DMX Connector Out XLR 3P
Data Connector In USB

Mechanical Specifications
Length (mm) 75 mm (2.953?)
Width (mm) 35 mm (1.378?)
Height (mm) 35 mm (1.378?)
Weight 0.08 kg (0.176 lb)
IP Rating IP20 (indoor use only)
Housing Metal
Colour Black

Product Properties
LED Indicators Power, Signal

Thermal Specifications
Maximum Ambient Temperature 40 °C (104 °F)
