Showtec Easy 16

16-channel faders
32 DMX channels
12 Programmable scenes
Built-in chase

This unit is a 32 channel programmable DMX controller. It is possible to program 12 scenes. Furthermore there is a built-in chase, adjustable speed, chase direction and fade time. This light controller is the best solution for small light shows or test set-ups.

Specifications:

Control and Programming
Control Mode DMX, Manual
DMX Channels 32
Buttons 20
Chases 1
Faders 16
Memories 12

Electrical Specifications and Connections
Power Supply 230 V AC 50 Hz (Power adapter)
Output voltage 9 V DC
Power Consumption 4.5 W
Power Connector In Low Voltage DC plug
DMX Connector Out XLR 3P

Power Adapter
Adapter type AC-DC adapter
Input voltage 230 V AC, 50/60 Hz V
Output voltage 9 V DC

Mechanical Specifications
Width (mm) 535 mm (21.063?)
Depth (mm) 195 mm (7.677?)
Height (mm) 90 mm (3.543?)
Weight 2.8 kg (6.173 lb)
Rack Units 3 U
IP Rating IP20 (indoor use only)
Housing Metal
Colour Gray

Product Properties
LED Indicators Signal

Thermal Specifications
Maximum Ambient Temperature 40 °C (104 °F)

Included Items
Included Cables None
Included Accessories DC power adapter
