Intelligent 1-fader LED DMX controller
Suitable for 3 to 6 colour LEDs
12 fixed and 12 user colours
12 fixed and 12 user chases with up to 99 steps
Manual, Auto run and Sound-controlled mode
The Showtec ColourCue 1 is an intelligent 1-fader LED DMX controller with 6 channels for easily controlling the light output of LED fixtures with up to 6 colours (RGBWA-UV), suitable for any venue. Its 6 rotary encoders enable you to quickly tune the lights to your desired colour, from 3-colour RGB to 6-colour RGBWA-UV. The ColourCue 1 enables you to create your own 12 preset colours and you can choose between 12 fixed colours. You can create up to 12 programs (chases) with each up to 99 steps for changing colours and effects in a loop. The chases can be controlled in Manual, Auto run or Sound-controlled mode.
Specifications:
Control and Programming
Control Mode Built-in Program, Manual, Sound, Static Dimmer
DMX Channels 6
Protocols DMX
Buttons 24
Faders 1
Memories 1212
Electrical Specifications and Connections
Power Supply 100-240 V AC 50/60 Hz (Power adapter)
Power Consumption 10 W
Power Connector In Low Voltage DC plug
DMX Connector Out XLR 3P
Audio Triggers 1
Power Adapter
Adapter type AC-DC adapter
Input voltage 100-240 V AC, 50/60 Hz V
Output voltage 12 V DC
Output current DC (mA) 1500 mA
Mechanical Specifications
Length (mm) 258 mm (10.158?)
Width (mm) 150 mm (5.906?)
Height (mm) 79 mm (3.11?)
Installation Depth (Excl. Connector) 79 mm (3.11?)
Weight 1.1 kg (2.425 lb)
Rack Units 3 U
IP Rating IP20 (indoor use only)
Housing Metal
Colour Gray, Orange
Product Properties
LED Indicators Operation mode, Output level
Thermal Specifications
Maximum Ambient Temperature 40 °C (104 °F)
Included Items
Included Cables None
Included Accessories Adapter
