Chassis on PCB
Colour code
X-type plugs
Box protection cover
Specifications:
Electrical Specifications and Connections
Connector 1 XLR 3P
Connector 2 XLR 3P
Cable Length 15 m
Pins 3
Inputs
Mono Inputs 12
Outputs
Main Outputs 4
Mechanical Specifications
Length (mm) 233 mm (9.173?)
Height (mm) 64 mm (2.52?)
Width (mm) 136 mm (5.354?)
Weight 5 kg (11.023 lb)
Material PVC
Housing Iron
Colour Black, Red
Product Properties
1st Shield Braided
2nd Shield Aluminium foil
Conductors 3
Number of Pairs 16
Included Items
Included Accessories Bag
