The Allen & Heath ZEDi-10FX combines the warmth of an analog mixer with the flexibility of a 4-in/4-out 24-bit/96kHz USB audio interface and professional-grade effects. Designed for musicians podcasters and small venues it features four GSPre mic/line inputs two stereo line channels Hi-Z instrument-ready inputs and 16 studio-quality FX presets. Ruggedly built for live or studio use the ZEDi-10FX also includes Cubase LE software for powerful recording and production capabilities straight out of the box.
Features:
4 mono mic/line inputs with GSPre preamps for high-fidelity audio
2 stereo line channels for keyboards, playback, or external devices
16 onboard studio-quality digital FX including reverb, delay, and modulation
24-bit/96kHz USB interface with 4-in/4-out operation for flexible DAW integration
Hi-Z input switches on mono channels for direct connection of guitars
3-band EQ on mono inputs and 2-band EQ on stereo inputs
48V phantom power for condenser microphones
Rugged all-metal chassis built for touring and studio durability
Smooth 60mm main mix fader for precise output control
Bundled with Cubase LE and Cubasis LE for music production
Inputs: 4 x XLR/TRS combo mic/line, 2 x 1/4" TRS stereo line
Outputs: 2 x XLR main, 1 x 1/4" TRS headphone, 1 x 1/4" TRS aux, 1 x 1/4" TRS FX, 2 x RCA monitor
USB Interface: 4-in/4-out, 24-bit/96kHz
FX Engine: 16 built-in digital effects
EQ: 3-band EQ (High: 12kHz, Mid: 2.5kHz, Low: 80Hz) on mono; 2-band EQ on stereo
Phantom Power: 48V, switchable
Dimensions (W x D x H): 332.7 x 274.3 x 96.5mm
Weight: 2.2kg
