The Allen & Heath ZED-12FX is a compact 12-channel mixer offering professional sound quality versatile input options and 16 studio-grade digital effects. Perfect for bands venues and project studios it features six GSPre mic/line channels three stereo channels USB audio connectivity for easy recording and playback and an FX engine with reverb delay and modulation presets. Built for live sound and recording flexibility the ZED-12FX is housed in a rugged steel chassis with intuitive controls and reliable Allen & Heath performance.
Features:
6 mono mic/line inputs with GSPre preamps for rich, detailed sound
3 stereo line inputs for keyboards, playback, or external gear
16 built-in digital effects including reverb, delay, and modulation
USB interface for 2-in/2-out recording and playback
3-band EQ with swept mids on mono channels for precise tonal control
2 stereo returns for FX and monitoring flexibility
2 aux sends (1 pre, 1 post) plus FX send
Rugged, all-metal chassis with intuitive layout and pro-level connectors
LED metering and smooth 60mm faders for accurate level control
Mono Channels: 6 x XLR/TRS combo with GSPre preamps
Stereo Channels: 3 x TRS stereo pairs
USB Audio: 2-in/2-out, 16-bit/48kHz
FX Engine: 16 onboard digital effects with tap tempo and FX send
EQ: 3-band EQ with sweepable mid on mono; 2-band on stereo
Aux Sends: 2 aux (1 pre, 1 post), 1 FX
Main Outputs: XLR (L/R)
Headphone Out: 1 x 1/4" TRS
Phantom Power: 48V, switchable
Dimensions (W x D x H): 385 x 465 x 98 mm
Weight: 5.1 kg
