Chassis on PCB
X-type plugs
Box protection cover
Specifications:
Electrical Specifications and Connections
Connector 1 XLR 3P
Connector 2 XLR 3P
Cable Length 10 m
Pins 3
Inputs
Mono Inputs 6
Mechanical Specifications
Length (mm) 205 mm (8.071?)
Height (mm) 53 mm (2.087?)
Width (mm) 64 mm (2.52?)
Weight 1.5 kg (3.307 lb)
Material PVC
Housing Aluminium
Colour Black
Product Properties
1st Shield Braided
2nd Shield Aluminium foil
Conductors 3
Number of Pairs 6
Included Items
Included Accessories Bag
