CASA-210B

Dual driver subwoofer cabinet for mobile and fixed sound reinforcement applications. Input from an amplifier is via 2 SPK connectors wired in parallel via a low pass filter to remove unwanted high and mid frequencies. Twin 10" woofers can handle a combined amplifier power of up to 600Wrms, delivering a punchy, rounded sound output. This sub unit can be positioned flat to accept a 35mm pole to mount a full-range speaker or upright for a smaller footprint. The form factor of this cabinet also makes it ideal for discreet installation.

Narrow footprint for discreet installation
Efficient front-loaded driver design

Construction     15mm MDF with durable polyurea finish
Hardware          Integral carry handle & 35mm pole mount socket
Inputs            2 x SPK connectors
Drivers            2 x 250mmØ (10") woofers
Impedance            4 Ohms total (8 Ohms each driver)
Frequency response          55Hz - 2kHz
Power handling : rms           600W
Power handling : max            1200W
Filter type            120Hz low pass 12dB/oct
Dimensions            690 x 480 x 305mm
Weight         30.0kg
